Pleated Air Filter

Pleated Air Filters

- MERV 10
- Available in 1", 2" and 4" depths
- Radial pleat design
- 100% synthetic media blend
- .026pt clay coated kraft board die cut frame
- Contains 10 pleats per linear foot of media
   (2" configuration, standard capacity)
- 15 pleats per linear foot of media for high capacity


Standard and High Capacity Medium Efficiency Pleated Air Filters

Our extended surface, pleats are designed for use in air filtration systems and equipment, as stand alone basic efficiency products or as pre-filters to higher efficiency bag, rigid box or cell type filter.

The 26 point clay coated, kraft-board die cut frame, diagonal and horizontal support members, radial wedge design and expanded metal media support create one of the most rigid filters of its type in the industry. The media pack, comprised of 100% polypropylene fibers, is bonded to the inside perimeter of the enclosure frame by a moisture resistant adhesive, providing a continuous and positive seal. The standard offering is rated by Underwriters Laboratories as Class II, per UL Standard 900. Our pleat is designed to work suitably within built up filter banks and/or side access systems. Available in nominal 1", 2" and 4" depths and 50 standard size offerings, this product is designed to fit most industrial and commercial applications with little or no system modification.

Rigid construction, extended surface and long service life are features and benefits which makes our filter an excellent option for meeting the requirements in today's filtration market.  Our pleated air filter media is bonded to expanded metal support grid using a water resistant adhesive. UL Class 2 rated as per UL 900 standard.

PLEATED AIR FILTER REPLACEMENTS FOR:

FLANDER PRE PLEAT®
PUROLATOR HI-E40
GRAINGER AIR HANDLER
3M FILTRETE™
MANY HOME FURNACE FILTERS

Two Capacity Options

Radial Wedge vs. Radial Pleats

standard and high capacity pleated filters radial wedge vs pleated air filter
